| 主要技術參數如下: | ||||||||
| 基本尺寸 | 型號 | 額定負荷 | 極限轉速 | 重量 | ||||
| d | D | B | 動負荷 | 靜負荷 | 脂潤滑 |
油潤滑 |
||
| 30 | 62 | 16 | QJS206 | 24.0 | 16.8 | 6500 | 8000 | 0.260 |
| 62 | 16 | QJ206 | 30.0 | 21.6 | 6800 | 8200 | 0.260 | |
| 72 | 19 | QJS306 | 37.2 | 26.5 | 5500 | 7000 | 0.480 | |
| 72 | 19 | QJ306 | 43.1 | 30.8 | 6000 | 7500 | 0.480 | |
| 35 | 72 | 17 | QJS207 | 28.0 | 24.0 | 6200 | 6800 | 0.360 |
| 72 | 17 | QJ207 | 31.3 | 27.0 | 6500 | 7200 | 0.360 | |
| 80 | 21 | QJS307 | 41.3 | 36.5 | 5800 | 6400 | 0.580 | |
| 80 | 21 | QJ307 | 18.5 | 41.6 | 6000 | 6600 | 0.580 | |
| 40 | 80 | 18 | QJS208 | 33.0 | 28.1 | 5900 | 6300 | 0.400 |
| 80 | 18 | QJ208 | 36.1 | 32.0 | 6100 | 6700 | 0.400 | |
| 90 | 23 | QJS308 | 56.8 | 50.8 | 5600 | 6100 | 0.850 | |
| 90 | 23 | QJ308 | 61.3 | 56.5 | 5900 | 6400 | 0.850 | |
| 45 | 85 | 19 | QJS209 | 36.4 | 33.8 | 5200 | 6500 | 0.450 |
| 85 | 19 | QJ209 | 39.2 | 35.2 | 5800 | 6600 | 0.450 | |
| 100 | 25 | QJS309 | 64.6 | 59.1 | 4600 | 5800 | 0.940 | |
| 100 | 25 | QJ309 | 73.1 | 68.2 | 5700 | 6300 | 0.940 | |
| 50 | 90 | 20 | QJS210 | 37.6 | 34.6 | 4800 | 5500 | 0.520 |
| 90 | 20 | QJ210 | 49.0 | 45.0 | 4800 | 5500 | 0.520 | |
| 110 | 27 | QJS310 | 66.2 | 62.8 | 4300 | 6000 | 1.280 | |
| 110 | 27 | QJ310 | 76.5 | 72.2 | 4600 | 6200 | 1.280 | |
